Technical Specifications
5000W Adjustable Fast Charging with Flexible Control
The PEVcharge PEV-5000-26 is a high-output adjustable fast charger with an adjustable output voltage range of 178V-252V and a maximum output power of 5000W.
With 220V AC input, the output current can be adjusted from 1A to 26A. With 110V AC input, the output current can be adjusted from 1A to 13A.
The charger supports both Bluetooth connection adjustment and touch screen adjustment, allowing the charging settings to be controlled according to the requirements of the connected battery and charging system.
This is not a universal charger. Compatibility with any battery or vehicle must be fully confirmed before ordering or use.
Key Highlights
- Maximum output power: 5000W
- Adjustable output voltage: 178V-252V
- With 220V AC input: 1A-26A adjustable output current
- With 110V AC input: 1A-13A adjustable output current
- Bluetooth connection adjustment
- Touch screen adjustment
- Included charging cable: XT90-XT90
- Included charging-port connectors: 2-Pin to XT90 + 5-Pin to XT90
- Both charging-port connectors are included together
- AC plug options: US / EU / UK / AU, choose one when ordering
- Protective portable carrying case included
- Size: 27 × 11 × 4.3 cm
- Bare unit weight: approximately 2165g
- 6-month warranty for normal use
Adjustable Output Voltage
The PEV-5000-26 supports an adjustable output voltage range of 178V-252V.
Before ordering or connecting the charger, confirm the battery’s required actual full-charge voltage.
A vehicle’s advertised voltage may be its nominal battery voltage rather than its actual full-charge voltage. Do not select this charger only according to a vehicle name, product name, model number, or advertised nominal voltage.
A required charging voltage falling within the charger’s adjustable output range does not, by itself, confirm compatibility.
The charging-port connector, connector wiring, polarity, BMS charging-current limit, vehicle charging-port limit, adapter rating, and cable rating must also be confirmed before use.
Adjustable Output Current
The available adjustable output-current range depends on the AC input voltage:
- With 220V AC input: 1A-26A adjustable
- With 110V AC input: 1A-13A adjustable
The selected charging current must not exceed the maximum supported current of the battery, BMS, vehicle charging port, charging-port connector, adapter, or charging cable.
The charger’s maximum available output current does not mean that every connected battery or charging system can accept that current.
Higher-current charging must be used only after the complete charging system has been verified. A lower current should be selected when any part of the charging system does not support a higher current.
Actual charging performance may also depend on the AC input voltage, wall outlet, electrical circuit capacity, available input power, BMS limit, vehicle charging limit, connector rating, adapter rating, and cable rating.
Included Charging-Port Connectors
This product includes the following two charging-port connector adapters:
- 2-Pin charging-port connector to XT90
- 5-Pin charging-port connector to XT90
Both charging-port connector adapters are included together. They are not separate connector options.
Each included charging-port connector is converted to an XT90 connection for use with the included XT90-XT90 charging cable.
The connector pin count describes only the physical connector configuration. It does not confirm the charging voltage, wiring arrangement, polarity, or supported charging current.
A connector with the same appearance or pin count is not automatically compatible. The connector wiring and polarity must be verified before use.
If the connected product uses a different charging connector, a separate correctly wired adapter may be required. Any additional adapter must support the selected output voltage and charging current.
Included XT90-XT90 Charging Cable
This product includes an XT90-XT90 charging cable.
The XT90-XT90 charging cable connects the charger to one of the included XT90 charging-port connector adapters.
The included 2-Pin and 5-Pin charging-port connectors are each converted to an XT90 connection.
Before charging, confirm that the selected charging-port connector, XT90 connection, charging cable, vehicle charging port, wiring, and polarity are correctly matched.
Do not use a cable, connector, or adapter that is not rated for the selected output voltage and charging current.
Bluetooth and Touch Screen Adjustment
The PEV-5000-26 supports both Bluetooth connection adjustment and touch screen adjustment.
Supported charging settings can be adjusted through the Bluetooth connection or directly through the charger’s touch screen.
Before every charging session, confirm that the selected output voltage and charging current are correct for the connected battery and complete charging system.
AC Plug Options
The AC power cable can be selected according to the customer’s region:
- US Plug
- EU Plug
- UK Plug
- AU Plug
Please choose one AC plug option when placing your order.
Protective Portable Carrying Case Included
Each charger includes a protective portable carrying case for storing and transporting the charger and its included accessories.
The carrying case helps keep the charger, XT90-XT90 charging cable, charging-port connectors, and AC power cable organized during storage and transport.
Specifications
| Brand | PEVcharge |
| Model | PEV-5000-26 |
| Maximum Output Power | 5000W |
| AC Input | 110V-240V AC, 50/60Hz9 |
| DC Input | 220V-400V DC |
| Adjustable Output Voltage | 178V-252V |
| Output Current With 220V AC Input | 1A-26A adjustable |
| Output Current With 110V AC Input | 1A-13A adjustable |
| Adjustment Methods | Bluetooth connection adjustment / touch screen adjustment |
| Size | 27 × 11 × 4.3 cm |
| Bare Unit Weight | Approximately 2165g |
| Included Charging Cable | XT90-XT90 |
| Included Charging-Port Connectors | 2-Pin to XT90 + 5-Pin to XT90 |
| AC Plug Options | US / EU / UK / AU, choose one |
| Storage | Protective portable carrying case included |
| Compatibility Requirement | Full-charge voltage, connector, wiring, polarity, BMS limit, charging-port limit, adapter rating, and cable rating must be confirmed before use |
| Warranty Period | 6 months |
Compatibility Checklist
Before ordering or connecting the charger, confirm all of the following:
- Actual full-charge voltage required by the battery
- Charging-port connector type
- Connector wiring and polarity
- BMS maximum charging-current limit
- Vehicle charging-port current limit
- Charging cable and adapter current rating
- Available input voltage and electrical circuit capacity
Do not rely only on a product name, vehicle model, advertised nominal voltage, connector appearance, or connector pin count.
If any compatibility information is unclear, please contact customer service before ordering.
Important Safety Notice
Confirm the battery’s actual full-charge voltage, charging-port connector, connector wiring, polarity, BMS limit, charging-port rating, adapter rating, cable rating, and maximum supported charging current before ordering or use.
Do not use an incorrect output-voltage setting or unsupported charging current. Incorrect settings or incompatible connections may damage the battery, charger, charging port, connector, adapter, cable, or vehicle.
Do not assume compatibility only because the required charging voltage appears to be within the charger’s adjustable output range.
This charger should be used only by customers who understand their battery and charging-system requirements.
If you are unsure about any setting or connection, stop using the charger and contact customer service for confirmation.
What’s Included
- 1 × PEVcharge PEV-5000-26 Charger
- 1 × XT90-XT90 Charging Cable
- 1 × 2-Pin to XT90 Charging-Port Connector
- 1 × 5-Pin to XT90 Charging-Port Connector
- 1 × Selected AC Power Cable: US / EU / UK / AU, depending on the selected option
- 1 × Protective Portable Carrying Case
Vehicles, batteries, display devices, and any additional adapters or accessories shown in product images or videos are for demonstration reference only and are not included unless clearly listed above.
Shipping Notice
Shipping cost is calculated at checkout.
Shipping availability and cost depend on the delivery address and selected shipping method. Some areas may not be available for delivery or may require additional shipping fees.
For special regions or unclear delivery areas, please contact customer service before ordering.
Warranty
This charger includes a 6-month warranty. Warranty coverage applies to normal use only.
Warranty does not cover damage caused by incorrect voltage settings, unsupported charging current, incorrect connector wiring, wrong polarity, misuse, water damage, physical damage, unauthorized modification, unsuitable adapter or cable use, or use with an incompatible charging system.
